Calculate the capacitance in femtofarads on the output node of a 2-input NOR gate without an external load in a 0.35µm CMOS process. Assume NO diffusions are shared. Use: Wp = 9.6µm, Wn = 5.3µm, Lp = Ln = 0.35µm, Loverlap = 0.1µm, all diffusion lengths= 1.0µm, COX = 5fF/µm^2, Cjn = 0.9fF/µm^2, Cjp = 1.0fF/µm^2, Cjswn = 0.2fF/µm, Cjswp = 0.3fF/µm
Image text
Calculate the capacitance in femtofarads on the output node of a 2-input NOR gate without an external load in a 0.35µm CMOS process. Assume NO diffusions are shared. Use: Wp = 9.6µm, Wn = 5.3µm, Lp = Ln = 0.35µm, Loverlap = 0.1µm, all diffusion lengths= 1.0µm, COX = 5fF/µm^2, Cjn = 0.9fF/µm^2, Cjp = 1.0fF/µm^2, Cjswn = 0.2fF/µm, Cjswp = 0.3fF/µm
