For the amplifier circuit below, , given Kp = 2.6 mA/V2 assume λ = 0,

Question

Notify Me Bookmark

For the amplifier circuit below, , given Kp = 2.6 mA/V2 assume λ = 0, Vtp = −1.3 V, Q−point(0.6 mA, 3.5 V), VDC = 10 V, R1 = 250 K ohm, R2 = 267 K ohm, R3 = 7 Kohm, Rsig = 2 kohm. Determine the maximum magnitude in mV of source signal to keep the amplifier in the linear range.

For the amplifier circuit below, , given Kp = 2.6 mA/V2 assume λ = 0, Vtp = −1.3 V, Q−point(0.6 mA, 3.5 V), VDC = 10 V, R1 = 250 K ohm, R2 = 267 K ohm, R3 = 7 Kohm, Rsig = 2 kohm. Determine the maximum magnitude in mV of source signal to keep the amplifier in the linear range.

Image text

For the amplifier circuit below, , given

K p = 2.6 m A / V^{2}

assume

λ = 0, V t p = - 1.3 V, Q - p o i n t (0.6 m A, 3.5 V), V D C = 10 V

,

R_{1} = 250 K

ohm,

R_{2} = 267 K

ohm,

R_{3} = 7 K o h m, R_{sig} = 2 k o h m

. Determine the maximum magnitude in

m V

of source signal to keep the amplifier in the linear range.

◻
