For the devices in the circuit of Fig. P5.60, |Vt| = 1 V, λ = 0, μnCox = 50 μA/V2 , L = 1 μm, and W = 10 μm. Find V2 and I2. How do these values change if Q3 and Q4 are made to have W = 100 μm?
Image text
For the devices in the circuit of Fig. P5.60, |Vt| = 1 V, λ = 0, μnCox = 50 μA/V2 , L = 1 μm, and W = 10 μm. Find V2 and I2. How do these values change if Q3 and Q4 are made to have W = 100 μm?
![For the devices in the circuit of Fig. p4, |VT| = 0.5 V, λ = 0, μnCox = 400 μA/V2, L = 0.5 μm, and W = 0.5 μm. Find V2 and I2. How do these values change if Q3 and Q4 are made to have W = 5 μm? [15] Fig. p4](https://www.doubtrix.com/uploads/editor/6076140144WiwXErdLGy.jpg)
![For the MOSFETs (Q1, Q2, Q3 and Q4) in the following circuit ( Figure 3 ), VDD = 6 V, |Vt| = 1 V, λ = 0, μnC2 x = 56 μA/V2, L = (z+1)μm and W = 16 μm. Find V1 and I1. How do these values change if the width of Q1 and Q2 are made to have 10 W ? VDD = 6 V, μnCpx = 83 μA/V2, L = 4 μm, W = 33 μm]](https://www.doubtrix.com/uploads/editor/0894819344exAnJdzifR.png)
