In the circuit shown below, the transistor has a b of 200. what is the dc voltage at the collector? Replacing the BJT with one of the hybrid-p models (neglecting r0), draw the equivalent circuit of the amplifier. Find the input resistance Rib and Rin and the overall voltage gain (vo/vsig). For an output signal of 0.4V, what value of vsig and vb are required.
