Measurement of a circuit incorporating what is thought to be an ideal op amp shows the voltage at the op-amp output to be -2.000 V and that at the negative input to be -1.000 V. For the amplifier to be ideal, what would you expect the voltage at the positive input to be? If the measured voltage at the positive input is -1.005 V, what is likely to be the actual gain of the amplifier?
Image text
Measurement of a circuit incorporating what is thought to be an ideal op amp shows the voltage at the op-amp output to be -2.000 V and that at the negative input to be -1.000 V. For the amplifier to be ideal, what would you expect the voltage at the positive input to be? If the measured voltage at the positive input is -1.005 V, what is likely to be the actual gain of the amplifier?
![The circuit shown in Figure 5-1 is a CMOS logic gate of some type. NOTE: Alternative symbols! a) Fill in the table below showing the state of each MOSFET (ON or OFF) and the output voltage for each combination of input states. [10] If 0 V represents a logic low, and +5 V represents a logic high, what is the logic gate function of this circuit? [2] c) Determine the output resistance ROUT of the CMOS gate of Figure 5-1 for each combination of inputs. [8] NOTE: ROUT is the Thevenin Resistance of the Gate. It is the total resistance connected between VDD and the output OR between the output and GROUND, depending on the state of the MOSFET switches. GIVEN : rDSn = 190 ohm and rDSp = 350 ohm d) If this gate exhibits a worst-case Low-to-High (tpLH) propagation delay of 60nsec when driving a given capacitive load, what would you expect the worst-case High-to-Low (tpHL) propagation delay to be?](https://www.doubtrix.com/js/ckeditor/filemanager/connectors/php/editor/1696166621-A78cbckcnnk.png)
![The circuit shown in Figure 5-1 is a CMOS logic gate of some type. NOTE: Alternative symbols! a) Fill in the table below showing the state of each MOSFET (ON or OFF) and the output voltage for each combination of input states. [10] If 0 V represents a logic low, and +5 V represents a logic high, what is the logic gate function of this circuit? [2] c) Determine the output resistance ROUT of the CMOS gate of Figure 5-1 for each combination of inputs. [8] NOTE: ROUT is the Thevenin Resistance of the Gate. It is the total resistance connected between VDD and the output OR between the output and GROUND, depending on the state of the MOSFET switches. GIVEN : rDSn = 190 ohm and rDSp = 350 ohm d) If this gate exhibits a worst-case Low-to-High (tpLH) propagation delay of 60nsec when driving a given capacitive load, what would you expect the worst-case High-to-Low (tpHL) propagation delay to be?](https://www.doubtrix.com/js/ckeditor/filemanager/connectors/php/editor/1696166633-B90cmnnclj.png)
