Q - 5: If Pseudo-NMOS techniques are used to build a 3-input NOR gate with W/Lp = 2.6 and W/Ln = 7.4, what will be its worst case (maximum) output low voltage, VOL, in millivolts? Use: VDD = 2.5 V, VTN = 0.4 V, VTP = −0.6 V, k'n = 150 μA/V^2, k′p = 60 μA/V^2

Q - 5: If Pseudo-NMOS techniques are used to build a 3-input NOR gate with W/Lp = 2.6 and W/Ln = 7.4, what will be its worst case (maximum) output low voltage, VOL, in millivolts? Use: VDD = 2.5 V, VTN = 0.4 V, VTP = −0.6 V, k'n = 150 μA/V^2, k′p = 60 μA/V^2

Image text

Q - 5: If Pseudo-NMOS techniques are used to build a 3-input NOR gate with

W / L p = 2.6

and

W / L n = 7.4

, what will be its worst case (maximum) output low voltage, VOL, in millivolts? Use: VDD

= 2.5 V, V T N = 0.4 V, V T P = - 0.6 V, k k =

150 μ A / V^{\land} 2, k^{'} p = 60 μ A / V^{\land} 2
