The circuit shown below is an example of a common-source amplifier biased with a PMOS current mirror. The CMOS process used to fabricate the circuit results in NMOS transistors with unCox = 100 uA/V^2 , lambda_n = 0.1 V^-1 , and VThn = 0.4 V; and PMOS transistors with upCox = 50 uA/V^2, lambda_p = 0.2 V^-1 , and VThp =

The circuit shown below is an example of a common-source amplifier biased with a PMOS current mirror. The CMOS process used to fabricate the circuit results in NMOS transistors with unCox = 100 uA/V^2 , lambda_n = 0.1 V^-1 , and VThn = 0.4 V; and PMOS transistors with upCox = 50 uA/V^2, lambda_p = 0.2 V^-1 , and VThp =

Image text
The circuit shown below is an example of a common-source amplifier biased with a PMOS current mirror. The CMOS process used to fabricate the circuit results in NMOS transistors with unCox = 100 uA/V^2 , lambda_n = 0.1 V^-1 , and VThn = 0.4 V; and PMOS transistors with upCox = 50 uA/V^2, lambda_p = 0.2 V^-1 , and VThp =
