The transistor used in a portion of the TTL gate shown in the figure has a β = 100. The base-emitter voltage of is 0.7 V for a transistor in active region and 0.75 V for a transistor in saturation. If the sink current I = 1mA and the output is at logic 0, find the current IA?

The transistor used in a portion of the TTL gate shown in the figure has a β = 100. The base-emitter voltage of is 0.7 V for a transistor in active region and 0.75 V for a transistor in saturation. If the sink current I = 1mA and the output is at logic 0, find the current IA?

Image text
The transistor used in a portion of the TTL gate shown in the figure has a β = 100. The base-emitter voltage of is 0.7 V for a transistor in active region and 0.75 V for a transistor in saturation. If the sink current I = 1mA and the output is at logic 0, find the current IA?
