What will be the final output voltage in volts for a dynamic 4-input NOR gate if all the NMOS FETs have a logic "0" on their inputs. Assume the total capacitance on the output is 22fF, a 32.8nA leakage current discharges the output towards ground, and that the gate is clocked at 3MHz. Use: VDD = 3.3V, VTN = 0.7V, VTP = -0.7V, k'n = 100uA/V^2, k'p = 40uA/V^2
